TrueGrid® Mesh of the Human Heart

TrueGrid Mesh of the Human Heart
invisible spacer
invisible spacer Over the years, more than one model of the human heart has been built using TrueGrid®. This is the earliest model, dating back to the mid-90s. The original data was obtained experimentally and then converted into polygonal surfaces before being read into TrueGrid®.
invisible spacer
invisible spacer More recently, researchers at Duke University have produced a model of portions of the human heart as they analyze the propagation of electrical current flow. They also began with polygonal surface data. Their results have been published in the on-line Journal of Circulation Research, sponsored by the American Heart Association.
invisible spacer
